7200 Monitor Instruction Manual
13 Advanced Sensor Setup
The advanced sensor menu allows the user adjustment of important sensor related settings. These settings can have
a major impact on the operation/configuration of the instrument and should only be altered by experienced users or
under the supervision of Partech.
Select Equation
This is used to determine the type of equation used to determine the measured value, only certain equations can be
used for each type of sensor.
Adjust Exp Constants
These values are used to perform linearisation on certain sensor types. The default values have been determined
through extensive testing and should produce acceptable results in most applications. If the linearity of the system is
not acceptable, please contact Partech technical support.
Adjust X Values
These values along with the Y values are used to perform linearisation on certain sensor types by means of a lookup
table. The X values represent the input values to the table and the Y values are used to determine the linear output
values. For further information on the use of lookup table linearisation please contact Partech.
Adjust Y Values
See Adjust X values above.
Sensor Defaults
It is sometimes necessary to restore the default values for the selected sensor type such that the instrument is in a
known state. To load the sensor defaults, select Sensor Defaults and press OK. To prevent accidental use, the user
password must be entered prior to confirming the operation.
167300IM-Issue 12 Issue Date 14/10/2014 Page 29 of 50
