C-xxxxx displays the program name which comes from the CI.
A few seconds after the program being selected, the A/V signal will be delivered to the
related connectors on the back panel.
Video: You can configure the video parameters of programs in this submenu. Press the
<ENTER>-key to confirm or press the <EXIT>-key to cancel.
Video Standard: you can select Auto or SECAM or NTSC or PAL for the
composite video output.
Screen: select the screen mode: 4:3 Full, 16:9 Full or 4:3 Letterbox.
DVB Subtitle Lang: select the language of DVB Subtitle.
EBU Subtitle Lang: select the language of EBU Subtitle.
Subtitle Priority: configure the priority of Subtitle; choose whether DVB or EBU
should be first.
Fail Mode：choose which kind of picture will appear when signal is fail. You can
select Black Screen or No Sync or Still Picture
Audio: You can configure the audio settings in the submenu.
Audio1 Level: use the <
> < > < > < >-keys to modify the audio1 level
within this range: 0~99.
Audio1 Mode: select Stereo, Left, Right or Mono for soundtracks.
Audio1 Language: select the language of the audio.
Audio2 Level: use the <
> < > < > < >-keys to modify the audio2 level
within this range: 0~99.
Audio2 Mode: select Stereo, Left, Right or Mono for soundtracks.
Audio2 Language: select the language of the audio.
Status: It indicates the status of the decoder. It includes PMT, PN, A/V, Video and
Audio.
Program set up: In this menu, you could set the programs, including the BISS list and
output programs.
5.2.4 ASI1
You can configure the settings of ASI1 in this menu.
ASI1 Source: Press the <ENTER>-key and use the <
> or < >-key to roll up or
down to select the signal source of ASI output, there are 5 type of signal source
optional:
CI De-encrypted: the de-encrypted transport stream from CI functional block
will be delivered to the ASI output port on the back panel.
TUNER: the transport stream from Tuner block will be delivered to the ASI
