PBI DCH-5000P - 5 Menu Structure and Operation; Main Menu

PBI DCH-5000P
- 6 -
B1 TS/IP IP input/output port
B2 RS-232 serial port for printing information
B3 MANAGEMENT Interface as network management and software
upgrading
B4,B7 ASI2 OUT ASI2 output port
B5,B8 ASI1 OUT ASI1 output port(independently from ASI 1)
B8 ASI1 IN ASI1 input port
B9 ASI2 IN ASI2 input port
B10 SDI2 SDI 2 output port
B11 SDI1 SDI 1output port(same with B11)
B12 HDMI HDMI output port
B13 CVBS CVBS output port(BNC)
B15,B14,B18 Y,Pb,Pr YPbPr output port
B19 CVBS CVBS output port(RCA)
B16,B17 AUDIO1 Audio1 output port (RCA)
B20,B21 AUDIO2 Audio2 output port(RCA)
B22 AUDIO1 Audio1 output port (RS-232, AESEBU digital audio,
XLR balanced/unbalanced)
B23 AUDIO2 Audio2 output port (RS-232)
B24 TUNER OUT Tuner signal loop out
B25 TUNER IN Tuner signal input
B26 GND Grounding terminal
B27 Fuse V250V/2A fuse
B28 Socket AVC 90~250V input
5. Menu Structure and Operation
There is a 2×20 character LCD in front panel. After turn on power, it will show boot
information
First line is product name; Second line is IP address of this device. Press 〔ENTER〕
button to enter main menu:
Main Menu
Inputs Outputs System
