PBI DCH-5000P
- 7 -
(1) Input Setup Set input parameters
(2) Output Setup Set output parameters
(3) System Set system parameters
5.1 Inputs Menu
There are three options: Status and DVB-S2:
5.1.1 Status Menu
It contains four options, ASI1, ASI2, TUNER and IP IN, to show the status of signal
input:
ASI1: When signal from ASI1 input port is locked, it will display package format and
code rate; if signal is not locked, it will show Unlock.
ASI2: When signal from ASI2 input port is locked, it will display package format and
code rate; if signal is not locked, it will show Unlock.
TUNER: When signal from tuner input port is locked, it will display package format
and code rate; if signal is not locked, it will show Unlock.
IP IN: When signal from IP input port is locked, it will display package format and
code rate; if signal is not locked, it will show No link.
5.1.2 DVB-S2 Menu
There are 6 options to set QPSK parameters. After signal is locked, the TUNER LOCK
indicator on front panel will turn green.
LNB Frequency: Input LNB frequency
Satellite Frequency: Input downstream frequency of satellite
Symbol Rate: Input symbol rate of satellite
LNB Voltage: select the correct LNB voltage output of the F-connector: Off, 13 V, 18 V. <A>
Inputs
Status DVB-S2
Ethernet
