PBI DCH-5000P
- 4 -
The mounting environment should be relatively dust free, free of excessive vibration
and the ambient temperature between 0 ℃ to 40 ℃. Relative humidity of 20% to 80%
(non-condensed) is recommended.
Air intake for cooling is achieved via holes at the side of the device and the fans inside.
The air flow should not be obstructed. Therefore, the device has to be placed on a flat
surface, leaving some space at the sides of the device.
When in operation, the internal temperature should not exceed the limit of 70 ℃.
Caution
Do not connect AC power until you have verified that the line voltage is correct and the
proper fuses are installed. The equipment requires a power source of either 50/60 Hz at
110V or 50/60 Hz at 240V. The voltage ranges for these nominal voltage values are shown
in the table:
POWER REQUIREMENT
Input voltage 90-250 Vrms auto select
Frequency 47 to 63 Hz
Power 50 VA max. / 30 VA typical.
Current 110 V/0.27A or 240 V/0.125A typical
Caution
Be sure the supply voltage is within the specified range.
Checking the fuses
The recognized recommended fuses are size 5 by 20 mm, rate T 2.0A, 250 V (UL and
IEC approved).
The line fuse is housed in a small container besides the power connector on the rear
panel. To check the fuse, insert the tip of a screwdriver in the slot at the middle of the
container and pry gently to extend the fuse where there is a little tap and pull out the fuse
gently. The fuse is attached to the line module and cannot be removed.
3.1 Inspection and Test
Check if the devise has any visible damage. If everything seems all right, power can be
applied to the device. The main socket and fuse are located at the rear panel of the device.
When the device is turned on, verify that the display shows the following message:
Digital TV Processor (factory default unit-name)
