• When the user selects the ‘In-Band’ operation mode the scanner calculates the
frequency offset from the channel raster as shown in the second column of Table 1.
• When the user selects the ‘Guard-band’ mode the scanner needs additional
information to calculate the frequency offset since there is a +/-7.5 kHz ambiguity as
shown in column 3 of Table 2. In this mode the user has three choices for ‘frequency
offset’:
o ‘0’: The scanner automatically calculates the offset based on the table. In case
of +/- 7.5 kHz ambiguity the scanner defaults to -7.5 kHz. In that case other
modes should be used. See below.
o ‘1’: The scanner inserts +7.5 kHz offset for the channel raster.
o ‘2’: The scanner inserts -7.5 kHz offset for the channel raster.
• The scanner provides RP, RQ, CINR, Time offset values for primary and secondary
synchronization channels as well as reference signal.
• In order to monitor the standard LTE network, the user can initiate a separate eTOPN
LTE measurement.
LTE
BW
Frequency
Offset to
100kHz
Raster
In-Band RB
In-Band EARFCN difference to
Regular LTE
1.4MHz
-2.5kHz
N/A
N/A
+2.5kHz
N/A
N/A
3MHz
+7.5kHz
12
9
-7.5kHz
2
-9
5MHz
+7.5kHz
17, 22
9, 18
-7.5kHz
2, 7
-18, -9
10MHz
-2.5kHz
30, 35, 40, 45
10, 19, 28, 37
+2.5kHz
4, 9, 14, 19
-37, -28, -19, -10
15MHz
+7.5kHz
42, 47, 52, 57, 62, 67,
72
9, 18, 27, 36, 45, 54, 63
-7.5kHz
2, 7, 12, 17, 22, 27, 32
-63, -54, -45, -36, -27, -18, -9
20MHz
-2.5kHz
55, 60, 65, 70, 75, 80,
85, 90, 95
10, 19, 28, 37, 46, 55, 64, 73,
82
+2.5kHz
4, 9, 14, 19, 24, 29, 34,
39, 44,
-82, -73, -64, -55, -46, -37, -28,
-19, -10
Table 3: NB-IoT In Band
