PCTEL IBflex - Table 4: NB-Iot Guard Band

SeeGull
®
IBflex
®
Reference Manual
PCTEL, Inc. Page 41 of 42 Rev T
LTE
BW
Guard-Band EARFCN difference
to Regular LTE
Frequency Offset to 100kHz Raster
(kHz)
1.4MHz
N/A
N/A
N/A
N/A
3MHz
N/A
N/A
N/A
N/A
5MHz
24
+/- 7.5
-24
-/+ 7.5
10MHz
46, 47, 48, 49
-2.5, 2.5, +/- 7.5, -2.5
-46, -47, -48, -49
2.5, -2.5, -/+ 7.5, 2.5
15MHz
69, 70, 71, 72, 73, 74
+/- 7.5, -2.5, 2.5, +/- 7.5, -2.5, 2.5
-69, -70, -71, -72, -73, -74
-/+ 7.5, 2.5, -2.5, -/+ 7.5, 2.5, -2.5
20MHz
91, 92, 93, 94, 95, 96, 97, 98, 99
-2.5, 2.5, +/- 7.5, -2.5, 2.5, +/- 7.5, -
2.5, 2.5, +/- 7.5
-91, -92, -93, -94, -95, -96, -97, -
98, -99
2.5, -2.5, -/+ 7.5, 2.5, -2.5, -/+ 7.5,
2.5, -2.5, -/+ 7.5
Table 4: NB-IoT Guard Band
