SeeGull
®
IBflex
®
Reference Manual
PCTEL, Inc. Page 32 of 42 Rev T
9. Appendix A: SeeGull IBflex Specification
5G New Rad
io
Measurement Modes
NR TopN Signal : Synchronization channels (P-SS/S-SS) &
PBCH, SSB, Blind Scan
Data Modes
PCI, PSS-RP [dBm], SSS-RP [dBm], PSS-RQ [dB], SSS-RQ [dB],
SS-CINR [dB], SSS-CINR [dB],
RSPBCH-RP [dBm], RSPBCH-RQ [dB], RSPBCH-CINR [dB], SSB-
RP [dBm], SSB-RQ [dB],
SSB-CINR [dB], SSB-idx, SSB-RSSI, SSS-Delay Spread, Time
Offset
Channel Bandwidths
15/30KHz
Max. Number of Channels
12
Measurement Rates:
30/sec
Dynamic Range (CINR)
PSS/SSS
-10 to +33 dB
PBCH DMRS CINR
-8 to +40 dB
Min. Detection Level:
RP
-132 dBm (SCS @ 15 KHz)
Relative Accuracy (CINR):
PSS/SSS CINR
±2 dB
FD-LTE and TD
-LTE
Measurement Modes
Top N Synchronization Channel Reference Signal, (P-SCH/S-
SCH), and Resource Block (Wideband, Subband); Layer 3
Reporting; Unicast Synchronization Channel Reference
Signal and (P-SCH/S-SCH), Dynamic Spectrum Sharing
Data Modes
RP, RQ, CINR, Cyclic Prefix, Time Offsets, Delay Spread;
MIMO: Condition Number, ECQI, EPUT
Channel Bandwidths
1.4 / 3 / 5 / 10 / 15 / 20 MHz
Max. Number of Channels
24
Receive Modes
SISO; MIMO (2x2) (MIMO – IBflex Only)
Transmit Antenna
Configurations
1, 2, 4 (with path measurement)
Measurement Rates:
Sync Channel RS
LTE FDD: 50/sec; TD-LTE: 25/sec
Multicast RS
Dynamic Range (CINR)
@10 /15/20 MHz
RS
-26 to +40 dB
P-SCH/S -SCH
-10 to +18 dB
Multicast RS
-9 to +30 dB
Min. Detection Level:
RSRP
-140 dBm (RSRP @ 15 MHz)
Relative Accuracy (CINR):
P-SCH/S-SCH & RS
±1 dB
LTE-LAA
Measurement Modes
Quick Top N Reference Signal and Sync Signal (P-SCH/S-SCH)
Data Modes
RS_RP, RS_RQ, RS_CINR, RS_TimeOffset, PSCH_RP,
PSCH_RQ, PSCH_CINR, SSCH_RP, SSCH_RQ, SSCH_CINR
Channel Bandwidths
20 MHz
Max. Number of Channels
16
Receive Modes
MISO
Transmit Antenna
1, 2 (with path measurement)
