PCTEL IBflex - NB-IoT

SeeGull
®
IBflex
®
Reference Manual
PCTEL, Inc. Page 33 of 42 Rev T
Configurations
Measurement Rates:
Sync Channel RS
1 Sig 160ms, 4 Sig 182ms, 8 Sig 205ms, 16 Sig 249ms
Dynamic Range (CINR)
@20 MHz
RS
P-SCH/S -SCH
-11 to +25 dB
-10 to +18 dB
Min. Detection Level:
RSRP
-130 dBm (RSRP @ 20 MHz)
Relative Accuracy (CINR):
RS
RS ±2 dB (-10dB ~ +20dB)
NB-IoT
Measurement Modes
Top N NRS (Narrowband Reference Signal), NPSS
(Narrowband Primary Synchronization Signal), NSSS
(Narrowband Secondary Synchronization Signal) and Layer 3
Reporting, Blind Scan
Data Modes
NRS - RP, RQ, RSSI, CINR, Timeoffset. NPSS - RP, RQ, RSSI,
CINR. NSSS - RP, RQ, RSSI, CINR, Timeoffset
Operation Mode
In-Band, Guard-band, Standalone
Channel Bandwidths
180 kHz
Measurement Rates
190 ms
Dynamic Range
NRS_CINR
-10 to + 40 dB
Min. Detection Level
NRS_RP
-138 dBm
Relative Accuracy
NRS_CINR
±2
Maximum Number of PCIs
16
WCDMA
Measurement Modes
Top N Pilot, Layer 3 Reporting, Blind Scan
Data Modes
lo, Ec/Io, Aggregate Ec/Io, SIR, Rake Finger Count, Time
Offset, Delay Spread
Channel Bandwidths
200 kHz / 3.84 MHz
Max. Number of Channels
24
Measurement Rate
100/sec (High Speed Mode); 50/sec (High Dynamic Range
Mode)
Top N CPICH Dynamic
Range
EcIo
-26 dB
Min. Detection Level
-120 dBm (High Dynamic Range Mode)
Relative Accuracy
±1 dB
GSM
Measurement Modes
Color Code, Layer 3 Reporting, Blind Scan
Data Modes
BSIC, C/I, RSSI
Channel Bandwidths
30 kHz / 200 kHz
Measurement Rate
Up to 200 BSIC Decodes/sec
Dynamic Range
+2 dB C/I
Min. BSIC Detection Level
-110 dBm
Relative Accuracy
±1 dB
