CDMA/EV
-DO
Measurement Modes
Top N PN, Blind Scan
Data Modes
Ec, lo, Ec/Io, Aggregate Ec/Io, Pilot Delay, Delay Spread
Channel Bandwidths
30 kHz / 1.25 MHz
Max. Number of Channels
24
Measurement Rate
CDMA: 25/sec; EV-DO: 18/sec
Top N PN Dynamic Range
Ec/Io
CDMA: - 28 dB***; EV-DO: -18.5 dBm
Min. PN Det ec tion Level
CDMA: -130 dBm; EV-DO: -120 dBm
Relative Accuracy
±1 dB
Wi-Fi
Measurement Modes
ORiNOCO® USB-9100 (adapter is country specific)
Radio Configuration
802.11a/b/g/n, 802.11a/b/g/n/ac
Data Modes
Signal Strength, Noise Level, Channel Number, Channel
Bandwidth, BSSID, Device Name, SSID, Security Protocol,
802.11 Media, Beacon Interval, Channel Utilization,
Throughput
Frequency Range
2.4 – 2.483 GHz; 5.15 – 5.85 GHz (subject to country
regulations)
Measurement Rates
9/sec (Typical); 5/sec (Typical) for 802.11ac
P25
Measurement Modes
Decode, RSSI
Data Modes
SINR, RSSI, BER, Frame BER, Network ID, Auto
Classification of Phase and Modulation Type
Channel Bandwidths
12.5 Khz
Measurement Rate
14 Decodes/sec (maximum)
7 Decodes/sec (typical)
100 RSSI/sec
Dynamic Range
-1 dB minimum detection
Relative accuracy
Phase 1 C4FM and Phase 2
HDQPSK
SINR
RSSI
±1 dB over 8 to 25 dB; ±2 dB over 3 to 8 dB, 25 to 30 dB
±1 dB over -118 to -10 dBm
Adjacent channel rejection
49 dB
