PCTEL IBflex - Power Measurements

SeeGull
®
IBflex
®
Reference Manual
PCTEL, Inc. Page 35 of 42 Rev T
DMR
Measurement Modes
Decode, RSSI
Data Modes
SINR, RSSI, BER, Frame BER,
Channel Bandwidths
12.5 Khz
Measurement Rate
14 Decodes/sec (maximum)
7 Decodes/sec (typical)
100 RSSI/sec
Dynamic Range
-1 dB minimum detection
Accuracy
SINR
RSSI
±1 dB over 6 to 40 dB; ±2 dB over 3 to 6 dB
±1 dB over -118 to -10 dBm
Adjacent channel rejection
49 dB
TETRA
Measurement Modes
Decode, RSSI
Data Modes
SINR, RSSI, Frame BER, Color Code, MCC, MNC
Channel Bandwidths
25 Khz
Measurement Rate
6.5 Decodes/sec (maximum)
3.5 Decodes/sec (typical)
100 RSSI/sec
Dynamic Range
-2 dB minimum detection
Accuracy
SINR
RSSI
±2 dB over +8 to +20 dB; ±3 dB over +4 to +8 dB
±1 dB over -118 to -10 dBm
Adjacent channel rejection
20 dB
Power Measurements
Measurement Modes
RSSI
LTE, 5G NR
11,050 ch/sec
WCDMA, GSM, NB-
IoT
4,250 ch/sec
CDMA, EV-DO
8,500 ch/sec
Dynamic Range
-120 to -20 dBm @ 30 kHz
Absolut e Accuracy
±1 dB (across Basic RF Input Power Range)
ENHANCED POWER SCAN (EPS™) MEASUREMENTS
Channel Bandwidths
5 kHz to 20 MHz in 2.5 kHz Increments
Measurement Rate
1,000 MHz/sec @ 5 MHz (Typical)
Absolute Accuracy
±1 dB (across Basic RF Input Power Range)
SPECTRUM ANALYSIS MEASUREMENTS
Measurement Range
> 90 dB
Measurement Rate (Single
Sweep)
>270 MHz/sec
Accuracy
±1 dB (across Basic RF Input Power Range)
LTE POWER ANALYSIS MEASUREMENTS (Available for TD-LTE Only)
Channel Bandwidths
1.4 / 3 / 5 / 10 / 15 / 20 MHz
Measurement Rate
20 msec @ 5 MHz
Accuracy
±1 dB (across Basic RF Input Power Range)
