PCTEL IBflex - RF Characteristics

SeeGull
®
IBflex
®
Reference Manual
PCTEL, Inc. Page 36 of 42 Rev T
RF Characteristics
Measurement Modes
10 MHz – 6 GHz
Internally Generated
Spurious Response
-110 dBm (Typical)
Conducted Local Oscillator
-75 dBm Max.
RF Operating Range
In-Band
-15 dBm Max.
Desensitization
Adjacent Channel
>50 dB (CDMA/E V-DO)
Adjacent Channel
>55 dB (All Other Technologies)
Adjacent Channel
>65 dB
Safe RF Input Range
≤ 10 dBm
Frequency Accuracy
±0.05 ppm (GPS Locked); ± 0.1 ppm (GPS Unlocked)
Intermodulation-free
Dynamic Range
2 tone (level 2) @ -40 dBm, 6 GHz, -68 dBc (Typical),
-12.6 dBm TOI; @ -25 dBm, 6 GHz, -70 dBc (Typical), 10
dBm TOI
GPS
Measurement Modes
56 Channel Internal Receiver
Vertical Position Accuracy
±2.5 meters
Horizontal Accuracy
(Altitude)
2x Vertical Position Accuracy
Acquisition Time
Cold Start: <30 sec; Hot Start: <2 sec
Sensitivity (Tracking)
> -150 dBm
Physical
Measurement Modes
Normal and Power Save
Maximum Power (+8 to +16
VDC)
18W; Power Save: 10W
Size
Without Battery Pack
7.6” D x 4.4” W x 1.55” H (192 mm D x 111.8 mm W
x 39.4 mm H)
With Battery Pack
10.1” D x 4.4” W x 2.1” H (257.6 mm D x 111.8 mm
W x 53.1 mm H)
Weight
Without Batteries
2.4 lb (1.1 kg)
With Batteries
3.8 lb (1.7 kg)
Temperature Range
Operating: 0°C t o +50°C; Storage: - 40°C t o +85°C
Host Data Communications
Interface
USB 2.0, High Speed; Bluetooth
Data Storage
SD (32 GB) (IBflex Only)
Antenna Ports Wi-Fi
Communications Antenna
RF: SMA Female (50Ω); GPS: Male (50Ω) SMB
Safety (CE)
EN 62368-1: 2014
EMC
EN 301 489-1
Shock and Vibration
MIL-STD-810G, SAE J1455
RoHS
Compliant (6/6)
