M. Install protective cover fig 27
Fig 27
1、 Tighten the M6*40 a little only.
2、 Install protetive cover,
3、 Then tighten the bolt
70
71
72
77
Only use for 209C
High setting
Tighten the M6*30 bolt
Install protective cover for oil hose and
protective pipe
