Peak 210C - Connecting Cables

9
F. Connecting cables
G. Lay down aside the columns with cables and oil hoses installed, face the
open way of each columns.
Cables pass through from the
bottom of the carriages
Cables pass through
the
top plate of the carriages
Fig. 17
Fig. 18
74
210C overall width: 3516mm
210CX overall width:3666mm
Notch is relatively
attention
