Peak 210C - Check the Parts before Assembly; Parts in the Parts Box (76)

6
C. Check the parts before assembly
1
．
Packaged lift and hydraulic power unit (see Fig. 8)
2. Move the lift aside with a fork lift or hoist, and open the outer packing carefully
，
take off the parts from upper and inside the column, take out the parts box
，
check
the parts according to the shipment parts list (See Fig. 9).
3. Loose the screws of the upper package stand, take off the upper column and remove
the package stand.
4. Move aside the parts and check the parts according to the shipment parts list
4.1 For Model 210C (See Fig. 10,11).
Fig. 8
Shipment Parts
list
Serial number
Top beam
Fig. 9
76
Fig. 10
Parts in the shipment parts list
Fig. 11
Parts in the parts box (76)
Parts box.
