Peak 409A - 220 V Wire Connection and Circuit Diagram

25
6. 220V Wire connection and circuit diagram
6.1 Wire Connection diagram in the control box (See Fig. 52).
6.2 220V Wire connection of hydraulic power unit (See Fig. 53).
Motor wire (M1、M2) separately connected to two wires in the motor
M2 Blue
Earth wire
M1 Red
Fig. 52
Fig. 53
Wire
of
motor
High
limit
switch
wire
○
C
Power
wire
Wire
○
A
○
B
of
limit
switc
h on
cross
beam
Wire of
hydraulic
solenoid
valve
Air
solenoid
valve
wire
Lower
limit
switch
wire
○
D
