29
View c
d. Another side of the air line which
shown in view d connect to the
female quick fitting installed on the
platform
c.Tighten the oil hose of air line kit,
oil hose and the air line of the lift air
line system by tie kits and pass
them through the plastic protecting
hose
201-5
201-8
201-10
201-11
Air Pump
201-9
201-5
Connect the elastic Air line to the male
connector of the Rolling Jack Air Pump
View d
