Peak 409A - Page 38

36
Item
Part No.
Description
409
409A
410
410A
412
412A
412AX
41
10420251
Cross beam limit switch assy.
2
2
2
2
2
2
2
42
11420010A
Fixing plate for limit switch
1
1
1
1
1
1
1
43
10420225
Top limit switch assy.
1
1
1
1
1
1
1
44
11420203
Fixing Plate for Limit Switch
1
1
1
1
1
1
1
45
11420204
Wire protective cover
1
1
1
1
1
1
1
46
10420156
Protective Ring φ24
1
1
1
1
1
1
1
47
11420004
Pin for drive-in ramp
2
2
2
2
2
2
2
48
10420005
Socket set screw M5*8
4
4
4
4
4
4
4
49
11420003
Drive-in Ramp
2
2
2
2
2
2
2
49A
10620063
Roller for drive-in rapm
4
4
4
4
4
4
4
49B
11620043
Rolling Pin for drive-in ramp
4
4
4
4
4
4
4
49C
10209010
Snap Ring φ10
8
8
8
8
8
8
8
50
11420031-1
Tire Stop Plate
2
2
2
2
2
2
2
51
10420226
Low Limit Switch Assy.
1
1
1
1
1
1
1
52
10209066
Hex Nut M16
4
4
4
4
4
4
4
55
11420007
Platform Lock Plate
4
4
4
4
4
4
4
56
11410090
Cylinder Fixing ring
1
1
1
1
0
0
0
11420012A
0
0
0
0
1
1
1
57
10410081
Cylinder
1
1
1
1
0
0
0
10420012
0
0
0
0
1
1
1
58
11420626
Cable connecting plate
1
1
1
1
0
0
0
11430622
0
0
0
0
1
1
1
59
10420014
Hex Nut M27
1
1
1
1
1
1
1
60
10201005
Split Pin φ4*50
1
1
1
1
1
1
1
60A
10209056
Self Locking Nut M10
4
4
4
4
4
4
4
60B
10420217
Cable Limit Pin
4
4
4
4
4
4
4
61
10420009A
Protecting Plastic Pipe
1
1
1
1
1
1
1
62
10420009B
Protecting Plastic Pipe
1
1
1
1
1
1
1
63
10420016B
Protecting Plastic Pipe
1
1
1
1
1
1
1
64
10420249
Wires
○
A
1
1
1
1
1
1
1
65
10420250
Wires
○
B
1
1
0
0
0
0
0
10440043
0
0
1
1
1
1
1
66
10420168
White Winding Tapeφ10*2000mm
1
1
1
1
1
1
1
67
10420016A
Wires 4*2.5
2
*800mm
1
1
1
1
1
1
1
68
10420205
Wires 2*1
2
*750mm
2
2
2
2
2
2
2
69
10420500
Parts Box
1
0
0
0
0
0
0
10430500
0
1
0
0
0
0
0
10490500
0
0
1
0
0
0
0
10496500
0
0
0
1
0
0
0
10440500
0
0
0
0
1
0
0
10450500
0
0
0
0
0
1
1
70
10420273
① Cable L=3250mm
1
1
0
0
0
0
0
10490005
① Cable L=3725mm
0
0
1
1
0
0
0
10440078
① Cable L=3775mm
0
0
0
0
1
1
0
10450005
① Cable L=3850mm
0
0
0
0
0
0
1
71
10420274
② Cable L=9250mm
1
1
0
0
0
0
0
10490006
② Cable L=10125mm
0
0
1
1
0
0
0
10440081
② Cable L=10325mm
0
0
0
0
1
1
0
10450008
② Cable L=10400mm
0
0
0
0
0
0
1
72
10420272
③ Cable L=4850mm
1
1
0
0
0
0
0
10490004
③ Cable L=5325mm
0
0
1
1
0
0
0
10440079
③ Cable L=5380mm
0
0
0
0
1
1
0
10450006
③ Cable L=5455mm
0
0
0
0
0
0
1
73
10420271
④ Cable L=7645mm
1
1
0
0
0
0
0
10490003
④ Cable L=8520mm
0
0
1
1
0
0
0
10440080
④ Cable L=8710mm
0
0
0
0
1
1
0
10450007
④ Cable L=8785mm
0
0
0
0
0
0
1
74
10420166
90° fitting
1
1
1
1
1
1
1
75
10420243
Straight Fitting
1
1
1
1
1
1
1
Item
Part No.
Description
409
409A
410
410A
412
412A
412AX
