5
Due to our efforts for constant improvements,
features and specifications listed herein are subject to change without notice.
TM
®
SPECIFICATIONS
POWER AMP SECTION
Rated Power & Load:
20 W RMS into 4 ohms with DDT™ compression
Power @ Clipping: (typically)
(1 kHz, 120 V AC line)
24 W RMS into 4 ohms @ 1% THD
26 W RMS into 4 ohms @ 5% THD
Frequency Response:
+0, -2 dB, 80 Hz to 10 kHz, @ 20 W RMS into
4 ohms
Total Harmonic Distortion:
Less than 0.2%, 100 mW to 20 W RMS, 60 Hz to
10 kHz, 4 ohms, typically below 0.1%
DDT™ Dynamic Range:
Greater than 20 dB
DDT™ Maximum THD:
Below 0.1% THD for 6 dB overload
Below 1% THD for 14 dB overload
Hum & Noise:
Greater than 78 dB below rated power
Power Consumption:
Domestic: 50 watts @ 120 V AC, 50/60 Hz
Export: 50 watts @ 220/230-240 V AC, 50/60 Hz
Dimensions & Weight:
14.75" H x 13" W x 9.125" D
20.20 lbs.
PREAMP SECTION
The following specs are measured @ 1 kHz with the Low and
High EQ @ 10, Mid EQ @ 0. Nominal levels are with gain @ 5.
Minimum levels are with gain @ 10.
Preamp Input:
Impedance: High-Z, 220 k ohms
Nominal Input Level: -22 dBV, 80 mV RMS
Minimum Input Level: -40 dBV, 10 mV RMS
Maximum Input Level: 0 dBV, 1 V RMS
Headphone Output:
Load Impedance: 4 ohms or greater
Nominal Power Output: 100 mV into 4 ohms
(Stereo jack, monaural signal disconnects internal
speaker when phone plug is inserted)
System Hum & Noise @ Nominal Input Level:
(20 Hz to 20 kHz unweighted)
78 dB below rated power
Equalization:
Low, Mid, & High passive type with special filtering
and brightness
