Pedego ELEVATE - Crank Arm; Speed Sensor

18
Assembly Instructions
Area Component Fastener Tool Torque
Nm
Drivetrain Chainring Lockring TL-FC39
+ TL-
FC36/33
35-45 Nm
Crank Arms Pinch Bolts 5mm Allen
Key
12-14 Nm
Cap Shimano
TL-FC16
0.7-1.5 Nm
Pedals Axle Park TWB-
15
35-55 Nm
Speed Sensor Fixing Bolt 4mm Allen
Key
1.5-2 Nm
Fork Brake Caliper Fixing Bolts 5mm Allen
Key
6-8 Nm
Thru-axle Hand Lever 2.5mm
Allen Key
Medium
Pressure
Frame Brake Caliper Fixing Bolts 5mm Allen
Key
6-8 Nm
Drive Unit
Guard
Fixing Bolts 3/4mm
Allen Key
2-4 Nm
Rear Shock Fixing Bolts 5mm Allen
Key
8.8 Nm
Suspension Lower Pivot
Bolts
5mm Allen
Key
17.6 Nm
Main Rocker
Pivot
5/6mm
Allen Key
8.8 Nm
Upper Seatstay
Pivot
5mm Allen
Key
19.6 Nm
Pedego Elevate Torque Specications Continued
Continued on next page...
