Adjustments After Assembly
ADJUSTMENTS AFTER ASSEMBLY
Suspension Fork & Rear Shock - Baseline Air Pressure
& Sag Setup
• It is recommended starting with 30% sag front and rear. Refer
to the suspension manufacturer’s instruction manuals or videos
for initial setup.
⸰ RockShox Fork: https://trailhead.rockshox.com/en/
⸰ RockShox Rear Shock: https://www.sram.com/service
⸰ X-Fusion: http://www.xfusionshox.com/service
Suspension Fork & Rear Shock - Rebound Damping
Adjustment
• Rebound damping controls the suspension rebound speed of
the fork or shock after compression. Refer to the graphics on
the suspension fork and rear shock indicating rebound damping
adjustment direction.
• Adjust the suspension fork rebound damping slow enough
that when you compress and release the fork, the tire does not
bounce off the ground.
• Adjust the rear shock rebound damping so that the rebound
speed is slightly slower than the fork.
Suspension Fork Compression Damping & Lockout
Adjustment
• The suspension fork is equipped with a lockout knob on the top
of the right fork leg. This adjustment is best used when riding on
pavement or smooth terrain.
• Turn the knob completely clockwise to engage the lockout. Turn
the knob counter-clockwise to disable the lockout function.
Continued on next page...
