PEDEGO ELEVATE COMPONENT DIAGRAM
Frame:
Head tube
Top tube
Down tube
Seat tube
Seat stay
Chainstay
Dropout
Rear Shock
Brakes:
Front Caliper
Rear Caliper
Rotor
Drivetrain:
Chain
Cassette
Derailleur
Pedal
Wheels:
Hub
Spokes
Rim
Valve
Tire
Suspension Fork:
Crown
Stanchions
Lowers
QR Thru-axle
Shimano Steps E8000:
Cycle Computer
Assist Switch
Battery
Drive Unit
Front Chainring
Chain Device
Crank Arm
Speed Sensor
Spoke Magnet
1 1
1
1
1
1
2 2
2
2
2
2
3 3
3
3
4
4
5
3
3
4
4
4
5
6
7
8
9
5
6
7
8
Cockpit:
Stem
Handlebar
Grips
Shifter
Brake Levers
Headset
1
2
3
4
5
6
Pedego Elevate Component Diagram
