WHERE CAN THE EQUIPMENT BE INSTALLED?
The installation and/or commissioning of the equipment may be carried out in:
➢ Generator connection box;
➢ External panel near of the generator;
➢ Any place protected from the environment near the generator;
➢ This equipment is for internal use (IP00);
➢ This equipment can’t be installed outdoors. Due to climatic conditions such as rain can
oxidize its terminals causing malfunction of the equipment and consequently malfunction
of the generator;
➢ The installation of peripherals such as the extern potentiometer, switches and circuit
breakers must be installed near the equipment and in an easily accessible location;
➢ The installation should be done in a closed metal enclosure (grounded or not) so that the
terminals are inaccessible where there is no opening that allows access to the equipment
and access must be done by means of a tool (Philips wrench, etc) remembering that the
terminals of the equipment should not be exposed and the peripherals installed in order
to comply with the IEC61010-1 standard;
➢ This equipment can be installed in places that may be subject to vibration, heat, and
electromagnetic interface because it is designed to withstand such adverse conditions;
➢ Generator connection diagrams vary according to generator type taking into account
generator voltage, excitation current, whether the generator is with or without auxiliary
coil, etc. All of these diagrams are clearly described in this manual.
Failure to comply with the above recommendations may exempt the
supplier any liability for consequential damages, and loss of warranty on
the equipment or damaged part.
