Page 19
USER MANUAL
8. Connect the steam pipe to the cylinder flange sleeve and fix in place with the supplied clip (fig.
13, 14 e 15).
Fig. 13 Fig. 14 Fig. 15
Use only PEGO HUMIDIFIER steam hoses or others that are certified to withstand high
temperatures without any internal vulcanisation or release of harmful substances
occurring!
THE HOSE MUST NOT BE CHOKED, HAVE ANY WATER TRAPS (SIPHONS)
OR BE LONGER THAN 5 METRES!
For instructions on correct connection of the steam distribution line read Chapter 7 STEAM
DISTRIBUTION carefully.
