USER MANUAL
3. Unhook the rear retainer spring from the upper steam flange and
slide it off (Fig. 30).
Fig. 30
4. Raise the upper steam flange, detaching it from the cylinder
(fig. 31).
Fig. 31
5. Detach the electrical connector from the cylinder (fig. 32)
Fig. 32
6. Remove the cylinder from the lower flange by raising it (fig. 33) and then remove it from the
humidifier (fig. 34).
Fig. 33 Fig. 34
