TYING MACHINE FIXION 2
29_133084-G
2. The reel clips pivot horizontally and vertically as re-
quired.
3. To switch the cover over to the left-handed version:
Open the reel cover and unclip it.
4. Reverse the cover and clip it onto the reel.
5. Close the cover.
Note
In this configuration, the dispenser clips are on the
left of the belt, with the ties outlet towards the front.
14
