10. Close the swivel dispenser (11).
6.6. REPLACING THE TWISTER
1. Open the swivel dispenser (11) with the lock/unlock
button (10).
2. Manually hold the twister.
3. Loosen the screw with a flat screwdriver.
4. Remove the screw.
5. Remove the twister (18).
Tip
Use a flat screwdriver to detach the twister (18)
from the back plate.
