pellenc FIXION 2 - Replacement of the Upper Guide

TYING MACHINE FIXION 2
29_133084-G
6.4. REPLACEMENT OF THE UPPER GUIDE
1. Open the swivel dispenser (11) with the lock/unlock
button (10).
2. Manually remove and discard the upper guide (13).
3. Insert the new upper guide (13) to the stop under the
support roller.
4. Clip the new upper guide (13) into its position.
Important
The top guide (13) should be slid all the way back
and then clipped to the front of the tool.
You should hear a "click".
31
