pellenc FIXION 2 - 6.7. BUILT-IN BATTERY; 6.8. CHARGER

TYING MACHINE FIXION 2
29_133084-G
6. Position the new twister (18) in place.
Important
Check the positioning of the twister:
• the flat of the twister (18) must be on the flat of
the indexer.
Check the rotation direction of the twister (18):
• The smooth side of the twister should be on the
outside.
7. Position the screw.
8. Tighten the screw to a torque of 0.3 N.m using a flat
torque screwdriver.
5. Close the swivel dispenser (11).
6.7. BUILT-IN BATTERY
Important
The battery must be replaced only by an approved distributor. The integrated battery must be checked by
an authorised dealer PELLENC when the tool is serviced.
6.8. CHARGER
This does not need any particular maintenance, but must be kept in a dry, ventilated, dust-free place, away from heat.
35
