pellenc FIXION 2 - 6.5. REPLACING THE SUPPORT ROLLER

TYING MACHINE FIXION 2
29_133084-G
5. Close the swivel dispenser (11).
6.5. REPLACING THE SUPPORT ROLLER
1. Turn on the tying machine (on/off button (20), see
Section 5.1, “Tying machine on/off”).
2. Open the swivel dispenser (11) with the lock/unlock
button (10).
3. Manually remove the upper guide by hand (13).
32
