pellenc FIXION 2 - 5.5. INSERT THE TIES INTO THE TYING MACHINE

TYING MACHINE FIXION 2
29_133084-G
7. Cut and remove the 3 straps with the disgorging
scissors (5).
5.5. INSERT THE TIES INTO THE TYING MACHINE
Large tie band spool:
1. Insert the tie cord, flat, into the opening (15) of the
tying machine until the tie cord reaches the end stop.
Note
The tie band spool must unwind clockwise through
the outlet opening of the lateral dispenser (7).
Small tie band spool:
1. Insert the tie cord, flat, into the opening (15) of the
tying machine until the tie cord reaches the end stop.
2. Make sure the tie cord is inserted from below and
not from above.
Note
The tie band spool must unwind clockwise.
19
