TYING MACHINE FIXION 2
29_133084-G
4. COMMISSIONING
4.1. FITTING THE HOLSTER TO THE BELT
1. Detach the hook and loop strap (33).
2. Pull the hook and loop strap (33) out of the belt loop
(34).
3. Install the holster (1) on the belt (4).
Note
When fitting the holster on the right, ensure
that the hook and loop strap is on your right.
When fitting the holster on the left, ensure that
the hook and loop strap is on your left.
4. Position the hook and loop strap (33) on the holster
(1).
5. Slide the end of the hook and loop strap (33) into the
belt loop (34).
6. Pull and fasten the hook and loop strap (33).
7. Position the belt at waist level and adjust the tight-
ness with the tabs (35).
4.2. FITTING THE LATERAL DISPENSER EQUIPPED WITH THE LARGE TIE BAND SPOOL ONTO
THE BELT.
1. Clip the dispenser fitted with the large tie band spool
onto the belt.
Note
The reel cover is placed on the user’s right side by
default. This is so that the dispenser clips are on
the right of the belt, with the ties outlet towards the
front.
13
