TYING MACHINE FIXION 2
29_133084-G
3. Manually remove the upper guide by hand (13).
4. Extract the remaining tie cord with the disgorging
scissors (5).
5. Insert the upper guide (13) to the end stop, under
the support roller.
6. Clip the upper guide (13) into position.
Important
The top guide (13) should be slid all the way back
and then clipped to the front of the tool.
You should hear a "click".
23
