Prima 451 – User Manual 15
4. Specification
4.1
Physical D
i
m
e
n
s
i
on
s
NOTE: All data is approximate
Overall frame size:
Height x Width x Depth (cm)
139 x 71 x 70
Work
s
u
r
f
a
c
e
Height
86 cm
Size:
58 cm x 25 cm
Loading:
30 kg (66 lb) - evenly distributed.
Top shelf:
71 cm x 35 cm
Loading:
30 kg (66 lb) - evenly distributed.
Drawer (optional):
12 x 36 x 35
Loading:
10 kg (22 lb) - evenly distributed.
Castors:
Diameter: 125 mm (5 inches) All braked
Pole-mount
post
Bushed to accept 25.4 mm (1 inch) or 22 mm (7/8 inch) poles.
Loading:
30 kg (66 lb)
Gas
scavenging
fixing
Bracket on frame upright
Loading:
30 kg (66 lb)
Common gas outlet:
22 mm male taper with coaxial 15 mm female taper
connections
Mass
(weight):
110 kg (242 lb)
4.2 Gas
S
upp
li
e
s
Cylinders:
Warning
Use only non-magnetic cylinders with this machine. Steel
cylinders can cause serious injury or death if brought into
an MRI scanning room.
A maximum of two cylinder fittings can be specified.
All cylinder yokes are pin-indexed
Pipeline: Maximum of three pipeline inlets(oxygen, nitrous oxide, air).
Gas inlet connectors and pipeline supply hoses are territory
specific, to relevant national standards:
NIST connectors are for UK & Europe
DISS connectors for USA specification
SIS connectors for
A
us
t
ralia
Medical gas
colour c
od
e
s
:
*To comply with relevant national standards.
Oxygen Green or White*
Nitrous oxide Blue
Medical air Yellow or Black/White*
4.3
F
l
o
w
m
e
t
e
r
s
Flow
r
a
ng
e
s
:
Single flow tubes:
Oxygen / Air / Nitrous Oxide 0 - 10 L/min
Cascade flow tubes:
Oxygen / Air / Nitrous Oxide (1) 0 - 1000 ml/min
(2) 0 - 10 L/min (graduated 1 - 10 L/min)
