16 Prima 451 – User Manual
Specification
Flowmeter A cc u r a cy
The accuracy of the flowmeter tubes is ± 2.5% of full scale reading.
Flowmeter construction and d i m e n s i on s
Tubes and floats are matched, and must not be interchanged. Flowmeter tubes have antistatic coatings.
Tubes are length indexed:
Oxygen 260 mm (10.24 inch)
Nitrous oxide 250 mm (9.84 inch)
Air 240 mm (9.45 inch)
Scale length 152 mm (6 inch) minimum
4.4 Gas Pressures
USA/Canada/Japan U K
Pipeline s upp li e s :
Supply pressure: 280-600 kPa (40.6-87 psig) 280-600 kPa (40.6-87 psig)
Cylinder s upp li e s :
Supply pressure: 19 985 kPa (2900 psig) 19 985 kPa (2900 psig)
Reduced pressure from regulator (at 5
L/min flow)
310 kPa +15 kPa / -35 kPa
(45 psig +2 psig / -5 psig)
380 kPa +15 kPa / -35 kPa
(55 psig +2 psig / -5 psig)
Regulator diaphragm bursting pressure 2800 kPa (406 psig) 2800 kPa (406 psig)
Reduced pressure from secondary
regulators (at 5 L/min flow)
Oxygen and Nitrous Oxide 152 - 241 kPa (22 - 35 psig) 152 - 241 kPa (22 - 35 psig)
Air 207 - 283 kPa (30 - 41 psig) 207 - 283 kPa (30 - 41 psig)
Fresh gas
supply p r e ss u r e :
Safety valve 90 cmH2O 90 cmH2O
4.5 Auxiliary Gas O u t l e t s
O xy g e n: Two self sealing connections on rear of machine
Air (on machines with Air supply option): Two self sealing connections (mini-Schrader) on rear of machine.
Supply pressure
Pipeline supply: Gas is supplied at pipeline supply pressure (see above)
Cylinder supply: Gas is supplied at reduced pressure from cylinder regulator (see above)
Flow rate
Flow rate for each gas 60 L/mn maxmum
WARNIN
Flow rates greater than 60 L/mn could affect the fresh gas flow to the patent
4.6 Oxygen Failure Warning De v i c e s
1. Gas system whistle (see section 3.3.2)
2. Visual indicator, direct pressure operated (see section 3.3.4)
