Penn System 450 Series Installation Guide

Table 12: System 450 web UI Relay Output Configuration page user actions, descriptions, and references
Callout Identifier item name User actions, descriptions, references
Static IP Address Select Static IP Address to enable and configure a static IP address for your System 450
control system with communications.
C450 IP Address If you select the Static IP Address radio button, you must assign a unique IP address for
the C450 control module. Typically, the network administrator for the network the C450 is
connected to provides an IP address for your C450 communications control module.
The default C450 IP Address is 169.254.1.1.
Subnet Mask If you select the Static IP Address radio button, you must assign a subnet mask for the
C450 control module. Typically, the network administrator for the network that the C450 is
connected to provides the subnet mask for your C450 communications control module.
The default subnet mask is 255.255.0.0.
4
Default Gateway If you select the Static IP Address radio button, you must assign a default gateway address
for the modem, router, or switch that connects your C450 control module to the network.
Typically, the network administrator for the network that the C450 is connected to provides
the default gateway address for your C450 communications control module.
The default Default Gateway address is 169.254.1.2.
5 Automatically Obtain an IP
Address
Select Automatically Obtain an IP Address to obtain an IP address and the required
network settings from the network DHCP server.
6 Direct Connect Select Direct Connect when you are connecting the communications control module directly
to a laptop or desktop computer with an Ethernet cable.
The communications control module is shipped in the Direct Connect network mode. You
must establish a direct connection between the control and your computer to set up the
control module for connection to a local network and the Internet.
7 Site Name: Assign a site name for your System 450 control system with communications. The assigned
site name appears at the top of each web page to the right of System 450.
The site name must be 16 characters or less. A site name is not required.
8 WebUserName: Assign a web username for your System 450 control system.
The web username is used to log in to the System 450 web UI configuration pages. The web
username must be 16 characters or less.
A username is not required. If you do not assign a web username, users must leave the
username field blank when logging into the web UI. See System Overview page for more
information about username, password, and login.
The default web username is System450User1.
9 Web Password: Assign a Web Password for your System 450 control system.
The web password is used to log in to the System 450 web UI. The password must be 16
characters or less. A password is not required. If you do not assign a web password here,
users must leave the Password field blank when logging into the web UI. See System
Overview page for more information about username, password, and login. The default web
Password is Wx9jc3.
10 HTTP Port: Assign the port number to be used by the HTTP Server.
The default HTTP Port number is 80.
11 DNS Server IP: Enter the IP address of the DNS (Domain Name System) server that the C450 control module
queries to resolve Internet addresses when Dynamic DNS is enabled.
12 Service Provider: Select the dynamic DNS provider. Options include None (dynamic DNS not used) or
DynDNS.com.
13 Host Name: Enter the host name used by your dynamic DNS provider. Leave this field blank if your system
does not use dynamic DNS.
14 Username: Enter the username for the account that is set up with your dynamic DNS provider. Leave this
field blank if your system does not use dynamic DNS.
15 Password: Enter the password for the account that is set up with your dynamic DNS provider. Leave this
field blank if your system does not use dynamic DNS.
16 External IP: This field automatically displays the C450 communications control module’s IP address as
seen from the Internet. This address can be used to troubleshoot Internet connectivity issues
between the control module and the dynamic DNS provider.
System 450 Series Control Module with Ethernet Communications Installation Guide36
