Table 7: System 450 web UI Overview page descriptions, user actions, and references
Callout Identifier item name User actions, descriptions, references
9 Sn-3: Status Displays the current condition status sensed at Sn-3.
10 Communications status Displays the current status of communication between your System 450 communications
control module and the connected LAN, WAN, or Internet. Communications status is defined
as OK or FAIL.
11 Site name field Displays the assigned site name.
You have the option to assign a site name for your System 450 control system in the Site
Name: field in the Web Server section on the Network Configuration page.
See Network Configuration page for more information.
12 Analog Outputs status section Displays the setup values for each analog output in your control system, including the
configured control ramp icon, analog output name (NAME), output signal status (STATUS),
referenced sensor (SENS), setpoint (SP), end point (EP), output signal strength at setpoint
(OSP), output signal strength at end point (OEP), integration constant (I-C), output signal
update rate (UP-R), output signal dead band (bNd), and sensor failure mode (SNF).
See Analog Output Configuration page for more information on setting up analog outputs in
the System 450 web UI.
13 STATUS of Analog Output signal Displays the current status of each analog output in your control system as a percentage of
the total output signal strength range.
In this example, OUTA-1 (Analog Output 1) is providing an output signal that is 90% of the full
signal strength, and OUTA-2 (Analog Output 2) is providing an output signal that is 45% of the
full signal strength.
14 Relay Outputs status section Displays the setup values for each relay output in your control system, including relay name
(NAME), relay output status (STATUS), referenced sensor (SENS), relay on value (ON), relay off
value (OFF), on-delay value (ONd), off-delay value (OFFd), minimum on time (ONT), minimum
off time (OFFT) and sensor failure mode (SNF).
See Relay Output Configuration page for more information on setting up relay outputs in the
System 450 web UI.
15 STATUS of Relay Output Displays the current status of each relay output in your control system as either On or Off.
In this example, OUTR-3 (Relay Output 3) is off, and OUTR-4 (Relay Output 4) is on.
16 About button Click About to display the System 450 Control Firmware ssm number and version, the Control
CPU type, the Terminal Firmware ssm number and version, and the Terminal CPU type. This
information is used to troubleshoot advanced control and firmware problems. See About
page for more information.
System Configuration page
Figure 64 shows an example System Configuration page for a System 450 control system that is already configured and
in operation. The System Configuration page is the first page that appears when you log in to the System 450 web UI.
You can block access to the System 450 UI configuration pages by enabling a remote access lock. When remote access is
locked, you can access the System Overview page to view system status, but you cannot log in to the web UI and make
system changes. You enable and disable the remote access lock in the control module’s local UI (four-button touchpad
and LCD display).
The System Configuration page provides system status information (just as the Overview page does) and access to
the Sensor Configuration page, Analog Output Configuration pages, Relay Output Configuration pages, and Network
Configuration page. Table 8 provides descriptions, user actions, and references for the items called out in Figure 64.
System 450 Series Control Module with Ethernet Communications Installation Guide 27
