System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin
11
P 2.5 INWC (Pressure/in. W.C.) 0 to 2.5 0.1 to 2.5 0.02 0.1 DPT2650-2R5D-AB
P 5 INWC (Pressure/in. W.C.) 0 to 5.0 0.25 to 5.0 0.05 0.25 DPT2650-005D-AB
P 8 bAR (Pressure/bar) -1 to 8 -1 to 8 0.05 0.1 P499RCP-401C
P598RCPSN401C
P 10 INWC (Pressure/in. W.C.) 0 to 10 0.5 to 10 0.05 0.2 DPT2650-10D-AB
P 15 bAR (Pressure/bar) -1 to 15 -1 to 15 0.1 0.2 P499RCP-402C
P598RCPSN402C
P 30 bAR (Pressure/bar) 0 to 30 0 to 30 0.1 0.4 P499RCP-404C
P598RCPSN404C
P 50 bAR (Pressure/bar) 0 to 50 0 to 50 0.2 0.4 P499RCP-405C
P598RCPSN405C
P 100 PSI (Pressure/psi) 0 to 100 0 to 100 0.5 1 P499RAP-101C
P499RAP-101K
P499RCP-101C
P499RCP-101K
P598RAPSN101C
P598RAPSN101K
P598RCPSN101C
P598RCPSN101K
P 110
3
Hg/PSI (Pressure/Hg-psi) -10 to 100 -10 to 100 0.5 1 P499RAPS-100C
P499RAPS-100K
P499RCPS-100C
P499RCPS-100K
P598RAPSN100C
P598RAPSN100K
P598RCPSN100C
P598RCPSN100K
P 200 PSI (Pressure/psi) 0 to 200 0 to 200 1 1 P499RAP-102C
P499RAPS102C
P499RAPS102K
P499RCPS102C
P499RCPS102K
P598RAPSN102C
P598RAPSN102K
P598RCPSN102C
P598RCPSN102K
P 500 PSI (Pressure/psi) 0 to 500 90 to 500 1 5 P499RAP-105C
P499RAP-105K
P499RCP-105C
P499RCP-105K
P598RAPSN105C
P598RAPSN105K
P598RCPSN105C
P598RCPSN105K
Table 2: System 450 Sensor Types, Setup Values, and Sensor/Transducer Product Codes (Part 2 of 3)
Sensor
Type
Unit of Measurement
Value
(Condition/Units)
Effective
Sensing
Range
Range of
Usable
Values
1
Resolution
Increment
Value
Minimum
Proportional
or Control
Band
Sensor Product Type
Number
2
