IntelliBrite Controller Installation and User’s Guide
iv
IntelliBrite
®
Controller kit contents
The following items are included in the IntelliBrite Controller kit:
• IntelliBrite Controller, P/N 600054
• Gasket, P/N 619763
• Knob, P/N 690026
• Door, P/N 690027
• Screw kit, P/N 619764
• Installation and User’s Guide (this manual)
Note: Outlet box purchased separately (see page 3)
Technical Support
Sanford, North Carolina (8 AM - 8:00 PM ET)
Moorpark, California (8 AM
- 5:00 PM PT)
Phone: (800) 831-7133 - Fax: (800) 284-4151
www.pentair.com
Related manuals - Download the IntelliBrite LED Pool Light Installation and User’s
Guide (P/N 619675)
Contents
IntelliBrite Controller Overview ........................................................................... 1
Controls and Buttons .....................................................................................1
Selecting a Light Show or Fixed Color ...............................................................2
Hold and Recall Feature ....................................................................................2
Powering on the IntelliBrite light(s).....................................................................3
Troubleshooting .................................................................................................3
Outlet Box Specifications ................................................................................... 3
Installing an Outlet box for the IntelliBrite Controller ........................................ 4
Wiring an IntelliBrite Controller to IntelliBrite LED Lights ...................................5
Maximum wattage when using multiple lights with controller .............................5
12 VAC IntelliBrite LED Landscape Lights ....................................................... 5
IntelliBrite Controller System Wiring Diagram ....................................................6
Installing the IntelliBrite Controller in the Outlet box ..........................................7
Wiring IntelliBrite Landscape LED Lights ...........................................................8
Using the IntelliBrite Controller to control IntelliBrite
landscape LED lights .........................................................................................8
Maximum wattage when using multiple IntelliBrite LED lights
with the IntelliBrite Controller ............................................................................. 8
Wiring the IntelliBrite Controller to a 12 VAC Transformer..................................8
Troubleshooting for the IntelliBrite Controller .....................................................9

Pentair IntelliBrite Specifications

General

Housing Material	Polymer
Lens Material	Polycarbonate
IP Rating	IP68
Color Options	Multiple
Wattage	40W
Voltage	12V or 12 VAC
Control	Automation System
Installation	In-ground Pool
Lifespan	30, 000+ hours
Type	LED Pool Light
Light Color	Color changing
