Pentair PRF 1035CS - BRINE WELL ASSEMBLY CH20795

BRINE WELL ASSEMBLY CH20795
Item No. QTY Part No. Description
1.................1 ........ CH15013-1 .........Brine Well w/Slots
2.................1 ........ CH15062 ............Safety Brine Valve
3.................2 ........ CH15070 ............Grommet
4.................1 ........ CH16371-16 .......Tubing, 3/8" x 16" Long
5.................1 ........ CH15024 ............Cap, Brine Well 4" Dia. (Caplug
STP-4)
6.................1 ........ CH15064-1 .........Brine Float w/One Grommet (As
purchased)
7.................1 ........ CH15063-1 .........Air Check Assembly
8.................2 ........ BR10332 ............Tubing Insert, Brass
Not Shown
1 ........ CH20774 ............Overflow Fitting Assembly
1 ........ *CH15031-1 .......Overflow Elbow
1 ........ *CH15031-2 .......Overflow Nut
1 ........ *CH16331 ..........Gasket
*Parts included with CH20774 Overflow Fitting Assembly
5
8
7
6
1
4
3
2
8
16 • Matrix System 368/706W
