SPACOMMAND
®
Spa-Side Remote Installation and User’s Guide
12
Mud-box
Bracket
Screw (x2)
Slot (x4)
Upper screw hole used for
mud-box alignment
▼
▼
Top edge of spa
Cut the lower edge of the conduit to align
cable connector and bracket.
Spa wall coping
Use slots for vertical
bracket positioning
▼
▼
