49
Preparation and inspection
3
Inspection of the air/water feeding function
Warning
Use sterile water for inspection of the air/ water feeding function. Failure to do so may pose a
risk of infection.
Note
Refer to the separate IFU of water bottle assembly for details of the operating procedure.
1. Set the A / W - drain lever of the water bottle assembly at the “A / W” position.
A/W
DRAIN
Figure 3.50
2. Tap the pump icon on the touch panel of the video processor.
3. Set the pump level to "5" by moving an adjustment slider on the pump level menu.
4. Insert the distal end of the endoscope into a container filled with sterile water, and check that air
bubbles are not continuously discharged from the air/ water nozzle at the distal end of the endoscope.
Figure 3.51
To Next Page
