46
Preparation and inspection
3
3-5. Inspection of the endoscopic system
Inspection of the endoscopic image
Caution
Do NOT look directly at the light emitted from the distal end of the endoscope. The intense light
may cause eye injuries. Turn off the lamp when looking directly at the distal end of the endoscope.
Note
The following instructions regarding the operation of a video processor are general in nature. For
specifi c information regarding your video processor model, refer to the IFU provided with the
video processor.
1. Turn on the main power switch on the video processor.
2. Press and hold the On/ Standby switch on the lower right of the front panel on the video processor for
2 to 3 seconds.
Figure 3.45
3. Tap a Lamp icon on the touch panel of the video processor.
4. Check that the distal end of the endoscope emits light.
Figure 3.46
5. Check that the endoscopic image is clear and is displayed normally.
To Next Page
