[Auto focus :Target sighting by Power focus mode]
Å Loosen the telescope clamp and horizontal clamp screws.
Ç Point the telescope at the target using a collimator.
É Tighten the above two screws.
Ñ Adjust the eyepiece.
Ö Look through the telescope,and then operate the Power focus key and focus on the target.
Ü Align the reticle accurately on the target using telescope and horizontal tangent screws.
Collimator Target
Collimator
Power focus key
Target sighting
• Tilting the Power focus key “clockwise” makes it possible to focus on closer objects and
“counterclockwise” will focus on farther objects.
• Tilting angle of the Power focus key makes it possible to perform following three focusing speeds.
Low speed: When tilted to middle position by approx. 5 degrees
Middle speed: When tilted fully by approx. 10 degrees
High speed: When tilted fully by approx. 10 degrees and passed one second
• Operating the Power focus key rotates the Focus ring, so do not touch it while it is rotating.
