Absolute rotary encoder P**58
Installation
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
9
The connection lines to the rotary encoder must be laid at a great distance (or sepa-
rated in different compartments) from power lines that could cause interference. To
ensure reliable data transfer, completely shielded cables must be used, and care
must be taken to ground them properly.
Wiring jobs, and opening or closing electrical connections must only be performed
when no voltage is present. Short circuits, voltage spikes and similar phenomena may
result in improper functionality and uncontrolled states. They may also cause
significant injury to persons or damage to property.
Before turning on the system, check all electrical connections. Connections that are
not made correctly can result in improper functionality of the system. Wrong
connections may result in significant injury to persons or damage to property.
