Absolute rotary encoder P**58
Technical data
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
40
8.4.3 Rotary encoder with recessed hollow shaft
Singleturn design
Multiturn design
Cable gland PG9, radial
max. insertion
depth = 30
min. insertion
depth = 15
Lay-on edge torque rest
* shaft can be reduced to ø10F7 or ø12F7 by using an adapter
Recessed hollow shaft
3.3
1.3
3.2
63.5
15
ø5.5 ... ø9
72
ø63
20
20˚
ø59
23
100
30
20 20
~32
ø60
ø15F7*
Cable gland PG9, radial
max. insertion
depth = 30
min. insertion
depth = 15
Lay-on edge torque rest
* shaft can be reduced to ø10F7 or ø12F7 by using an adapter
Recessed hollow shaft
3.3
1.3
3.2
63.5
15
ø5.5 ... ø9
72
ø63
20
20˚
ø59
23
112
30
20 20
~32
ø60
ø15F7*
