Peri MULTIFLEX - GT 24 Girder

8
perm. A
n,End
= 16 kN
perm. A
m,End
= 13 kN
perm. A
n
= 28 kN
perm. M
n
= 7.0 kNm
perm. A
m
= 20 kN
perm. M
m
= 4.0 kNm
Permissible internal forces and bearing forces
Permissible shear force perm. Q = 13.0 kN
Permissible bearing force in the nodes (+/- 2 cm) perm. A
n
= 28.0 kN
Permissible bearing force between the nodes perm. A
m
= 20.0 kN
Permissible bending moment perm. M = 7.0 kNm
Permissible support moment (for support directly under the nodes) perm. M
n
= 7.0 kNm
Permissible support moment (support between the nodes) perm. M
m
= 4.0 kNm
Bending stiffness EI = 887 kNm²
End supports for single spans and
continuous girders
Supports for continuous and
cantilevered girders
GT 24 Girder
min. 16 cm
min. 16 cm
l
A
l
A
+–
–+
–+–+ –+–+
l
A
l
A
For carrying the maximum bearing force into
the GT 24 girder, the support lengths l
A
must
have the following minimum dimensions:
13.5 cm for support directly under the nodes,
14.5 cm for support between the nodes.
A2 Components
MULTIFLEX Girder Slab Formwork
Assembly Instructions for Standard Configuration
