Peri MULTIFLEX - PEP 30 with Base MP 50 Prop Loads

43
PEP 30 – 250
L = 1.46 – 2.50 m
PEP 30 – 300
L = 1.71 – 3.00 m
PEP 30 – 350
L = 1.96 – 3.50 m
PEP 30 – 400
L = 2.21 – 4.00 m
2 . 0 0 4 1. 6 4 1. 6
2 . 10 4 1. 6 4 1. 6
2.20 41.6 41.6
2.30 38.9 41.6 41.6 41.6
2.40 36.1 41.6 41.6 41.6
2.50 33.9 41.6 41.6 41.6 44.1 44.1
2.60 32.2 41.0 41.6 41.6 44.1 44.1
2.70 30.8 38.7 41.6 41.6 44.1 44.1
2.80 29.7 35.3 40.3 41.6 44.1 44.1 40.3 40.3
2.90 27.5 31.3 38.3 41.6 44.1 44.1 40.3 40.3
3.00 25.9 27.6 36.5 41.3 44.1 44.1 40.3 40.3
3.10 35.1 40.0 44.1 44.1 40.3 40.3
3.20 32.9 36.8 43.8 44.1 40.3 40.3
3.30 31.1 33.2 41.7 44.1 40.3 40.3
3.40 28.5 30.3 38.8 41.8 40.3 40.3
3.50 26.1 27.1 37.1 39.7 40.3 40.3
3.60 34.8 36.5 40.3 40.3
3.70 32.4 33.5 40.3 40.3
3.80 30.0 30.9 40.3 40.3
3.90 27.8 28.7 40.3 40.3
4.00 25.6 26.3 39.4 40.3
4.10 36.7 37.9
4.20 34.3 35.2
4.30 32.0 32.9
4.40 29.9 30.5
4.50 27.6 28.2
Slab Props
PEP 30 with Base MP 50
Permissible Prop Load [kN] according to the Type Test
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Overall Height [m] (prop extension + 50 cm)
