Peri MULTIFLEX - VT 20 K Girders with Steel Cap

MULTIFLEX Girder Slab Formwork
49
Item no. Weight kg
028870 5.430 Lowering Head 20/24, galv.
For tilt-resistant support of one or two GT 24 or
VT 20 Girders.
Lowering range 4 cm.
Note
Required hole diameter of the prop end plate
Ø 40 mm.
Girder overlap on both sides minimum 16.3 cm for
GT 24 and 15 cm for VT 20.
1
9

4
2
1
0
1
3
6
210
1
2

240 
170 

074990
074905
074910
074890
074920
074930
074940
074950
074960
074970
074980
8.560
12.700
14.460
15.640
17.110
19.470
21.240
23.010
26.550
28.910
34.810
Girders VT 20K with Steel Cap
Girder VT 20K, l = 1.45 m
Girder VT 20K, l = 2.15 m
Girder VT 20K, l = 2.45 m
Girder VT 20K, l = 2.65 m
Girder VT 20K, l = 2.90 m
Girder VT 20K, l = 3.30 m
Girder VT 20K, l = 3.60 m
Girder VT 20K, l = 3,90 m
Girder VT 20K, l = 4.50 m
Girder VT 20K, l = 4.90 m
Girder VT 20K, l = 5.90 m
L
1445
2150
2450
2650
2900
3290
3590
3890
4490
4900
5900














  







/
