Illustration 20 g06237691
Typical example
(15) Water temperature regulator valve
(Thermostat)
(16) Water temperature sensor
(17) Alternator drive belt
(18) Vibration damper
(19) Water pump
(20) Oil drain plug (rear)
(21) Oil cooler
(22) Flywheel housing
(23) Exhaust manifolds
i10082735
Product Description
The Perkins 2806A-E18TA, 2806A-E18TTA, 2806C-
E18TA, 2806C-E18TTA, and the 2806D-E18TA
industrial engines have the following characteristics:
• Four-stroke cycle
• Mechanically actuated, electronically controlled
fuel injection system
• Turbocharged
• Air to air charged cooled
Engine Specifications
Note: The front end of the engine is opposite the
flywheel end of the engine. The left and the right
sides of the engine are determined from the flywheel
end. The number 1 cylinder is the front cylinder.
Illustration 21 g03857469
Cylinder and valve location
(A) Exhaust valve
(B) Inlet valve
SEBU9074-06
25
Product Information Section
Product Description
